ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural

  • ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural
  • ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural
  • ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural
  • ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural
  • ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural
Place of Origin China
Brand Name ANSTEEL
Certification API 5L,ISO9001,SGS,BV,CCIC
Model Number Q235 Q345
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Seaworthy Packing for Exporting
Delivery Time 7-10 days
Payment Terms L/C, T/T, Western Union
Supply Ability 50000 Tons/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Length As Requirement Testing Third Party Inspection Available
Specification As Requirement Delivery Time 7-10 Days
Package Seaworthy Standard Package MOQ 1 Ton
Highlight

S275jr Rolled Steel Section

,

S235jr Rolled Steel Section

,

hot rolled beam H
Leave a Message
Product Description

ASTM s235jr s275jr Rolled Steel Section H-beam Steel Hot Rolled



Product Description

Beams is also known as steel Beam , is a cross section for the h shape of strip steel.
I-steel regular i-steel and light beams, h-beam 3 kinds.
Beams are widely used in various building structures, Bridges, vehicles, stents, machinery, etc.
Common beams and light beams of the wing root to the edge thinning, has a certain Angle, ordinary beams and light beams on the number of models is to use its high waist centimeters of Arabic numerals, web plate, the thickness of the flange and flange width different specifications to waist high (h) * waist thick legs wide (b) (d) said the number of blessings, such as "sewing worker 160 x 88 x 6", it indicates that the waist high is 160 mm, width is 88 millimeter, the leg with a thickness of 6 mm ordinary beams.
 "light industry 160 x 81 x 5", it indicates that the waist high is 160 mm, the leg width is 81 millimeter, waist is 5 mm thick light beams.


H Beam Specification
size
w/m
size
w/m
size
w/m
100*50*5*7
9.54
250*255*14*14
82.2
400*400*13*21
172
100*100*6*8
17.2
294*200*8*12
57.3
400*408*21*21
197
125*60*6*8
13.3
300*150*6.5*9
37.3
414*405*18*28
233
125*125*6.5*9
23.8
294*302*12*12
85
440*300*11*18
124
148*100*6*9
21.4
300*300*10*15
94.5
446*199*7*11
66.7
150*75*5*7
14.3
300*305*15*15
106
450*200*9*14
76.5
150*150*7*10
31.9
338*351*13*13
106
482*300*11*15
115
175*90*5*8
18.2
340*250*9*14
79.7
488*300*11*18
129
175*175*7.5*11
40.3
344*354*16*16
131
496*199*9*14
79.5
194*150*6*9
31.2
346*174*6*9
41.8
500*200*10*16
89.6
198*99*4.5*7
18.5
350*175*7*11
50
582*300*12*17
137
200*100*5.5*8
21.7
344*348*10*16
115
588*300*12*20
151
200*200*8*12
50.5
350*350*12*19
137
596*199*10*15
95.1
200*204*12*12
72.28
388*402*15*15
141
600*200*11*17
106
244*175*7*11
44.1
390*300*10*16
107
700*300*13*24
185
244*252*11*11
64.4
394*398*11*18
147
792*300*14*22
191
248*124*5*8
25.8
400*150*8*13
55.8
800*300*14*26
210
250*125*6*9
29.7
396*199*7*11
56.7
900*300*16*28
243
250*250*9*14
72.4
400*200*8*13
66


Product Show

ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural 0





Package & Delivery

ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural 1





Certification

ASTM S235jr S275jr Hot Rolled H Beam Rolled Steel Section For Structural 2



FAQ
Q: Do you provide samples ?How can I get a sample to check your quality? Is it free or extra ?
A: Free samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.

Q: How is the quality of your products?
A: Our products are manufactured strictly according to national and international standard, and we take a test before delivered out. If you want see our quality certifications and all kinds of testing report, please just ask us for it.

Q: Are you factory or trader?
A: Our company has been manufacturing and selling steel products for many years since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
