Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
| Place of Origin | Jiangsu China |
|---|---|
| Brand Name | ANSTEEL |
| Certification | ASTM,GB,JIS,ASTM A1008 |
| Model Number | DD36 AH36 Q235B A36 SS400 1020 1045 1050 |
| Minimum Order Quantity | 2 Tons |
| Price | Negotiable |
| Packaging Details | Seaworthy Packing For Exporting |
| Delivery Time | 7-10 days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 50000 Tons/Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Key Word | Carbon Steel Plate | Grade | SAE1008 SAE1010 SAE1050 SAE1070 DH36 |
|---|---|---|---|
| Thickness | 0.6-200mm Or As Required | Standard | GB/T709-2006, ASTM A36, JIS G4051 |
| Width | 600-2300mm Or As Required | Sample | We Can Provide It If It Is In Stock. |
| Cutting Type | Laser Cutting;Water-Jet Cutting;Flame Cutting | Packing | Standard Seaworthy Packing |
| Highlight | Marine hot rolled carbon steel plate,AH36 hot rolled carbon steel plate,Shipbuilding hot rolled carbon steel plate |
||
Product Description
Shipbuilding Marine Carbon Steel Plate AH36 DH36 Hot Rolled 10mm 12mm Mill Inspection
Product Introduction
DH36 ship plate is a high-strength ship plate. Ship steel generally refers to steel for hull structure. It is a steel used to manufacture hull structure produced according to the construction specifications of classification societies. DH36 has good comprehensive mechanical properties, welding properties, and process properties. It is suitable for manufacturing hull structures of ocean-going, coastal and inland waterways, docks, oil platforms, pipelines in the sea, coastal power plants, dock facilities and other structural parts.
| Standard | CCS,ABS |
| Grade | A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36,A40/D40/E40/F40,A131A/B/D/E/ AH32/DH32/EH32/AH36/DH36/EH36/AH40/DH40/EH40,NVA420/D420/E420, NVA460/D460/E460,NVA500/D500/E500,NVA550/D550/E550…. |
| Thickness | 0.3-200mm (2-100mm usually used) |
| Width | 600-2300mm (1000-2200mm usually used) |
| Length | 1000-12000mm or as your request |
| Surface | Clean, finishing,blasting and painting according to customer requirement |
| Process | Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T, and other delivery states are available as required |
| Certificate | API,ISO,SGS,BV,CE etc |
| Quality | MTC will be provided with goods, third part inspection is acceptable, for example BV, SGS. |
| Package | Standard export seaworthy package,suit for all kinds of transport,or as required. |
| Container Size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
| 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) | |
| Trade term | Ex-Work,FOB,CFR,CIF,etc |
| Application | Widely used in a variety of architectural and engineering structures,such as |
| 1.) metal constructions such as buildings,bridges,ships; | |
| 2.) transmission tower, reaction tower; | |
| 3.) lifting transportation machinery; | |
| 4.) industrial furnace;boilers | |
| 5.) container frame, warehouse goods shelves, etc |
Chemical Composition
| Grade | C | Si | Mn | P | S | Als |
| A | ≤0.21 | ≤0.50 | ≥2.5C | ≤0.035 | ≤0.035 | |
| B | ≤0.21 | ≤0.35 | 0.8~1.2 | ≤0.035 | ≤0.035 | |
| D | ≤0.21 | ≤0.35 | 0.6~1.2 | ≤0.035 | ≤0.035 | ≥0.015 |
| E | ≤0.18 | ≤0.35 | 0.7~1.2 | ≤0.035 | ≤0.035 | ≥0.015 |
| AH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| DH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| EH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| AH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| DH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| EH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| AH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| DH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
| EH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 |
Test
We will control the quality from part of material steel plate, each plate produced will be have it is own identify label, quality will check the chemical component and physical property and then provide material test certificate. Size dimension will be checked and show pictures to customer to guarantee all goods will be meet requirement.
Cutting Service
Recommend Products
Application
Hot-rolled steel products are widely used in cold-rolled substrates, ships, cars, bridges, construction, machinery, oil pipelines, pressure vessels, etc. due to their excellent strength, good durability, easy processing and outstanding weldability.
Package & Delivery
Certification
FAQ
What are the shipping ports?
You can choose other ports shipping to your needs.
About the product price?
Due to the cyclical changes in raw material prices, prices vary from period to period.
What certifications do your products have?
We have ISO 9001, SGS, EWC and other certifications.
