G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing

  • G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing
  • G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing
  • G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing
Place of Origin China
Brand Name WISCO
Certification ISO 9001
Model Number SGCC,SECC,A653
Minimum Order Quantity 2 Tons
Price Negotiable
Packaging Details Seaworthy packing for exporting
Delivery Time 7-10 days
Payment Terms L/C, T/T, Western Union
Supply Ability 50000 Tons/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Galvanized Steel Coil Standard JIS G3302 / JIS G3312 /JIS G3321/ ASTM A653M / A924M 1998
Steel Grade CGCC DC51D+Z Hardness Hrb 60-90 (Soft - Full Hard)
Coating 30-275g Width 600mm-1250mm Or As Required
Application Industrial And Civil Construction, Steel Structure Buildings And Producing Roofing Sheets Edge Mill Edge, Cut Edge
Highlight

Roofing Galvanized Steel Coil

,

Z180 Galvanized Steel Coil

,

Full Hard Galvanized Steel Coil
Leave a Message
Product Description

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing


Product Parameters

Galvanized coil is a thin steel sheet in which a thin steel sheet is immersed in a molten zinc bath so that a layer of zinc is adhered to the surface. It is mainly produced by continuous galvanizing process, that is, galvanized steel plate is made by continuously immersing the rolled steel plate in a plating tank with molten zinc. This kind of steel plate is also manufactured by hot dip method, but immediately after being out of the tank, it is heated to about 500 ℃ to form an alloy coating of zinc and iron. This galvanized coil has good paint adhesion and weldability.

Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
DX51D, DX52D, DX53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil Sheet Plate Strip
Thickness
0.12-6.00mm or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement


Surface Treatment


Surface Treatment Type Code Feature
Chromic acid treatment C Good corrosion resistance, suitable for bare state
Chromic acid treatment + oiling S Good corrosion resistance
Phosphoric acid treatment (including sealing treatment) P A certain degree of corrosion resistance, good paint performance
Phosphoric acid treatment (including sealing treatment) + oiling Q It has certain corrosion resistance, good paint performance, and prevents rust during transportation and storage
Phosphoric acid treatment (excluding sealing treatment) T A certain degree of corrosion resistance, good paint performance
Phosphoric acid treatment (excluding sealing treatment) + oiling V Have certain corrosion resistance, good paint performance, and prevent rust
Oiled O Prevent rust during transportation and storage
No treatment M Suitable for immediate painting



Product Detail

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 0

Surface

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 1



Production Process



G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 2

Application

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 3

Packaging & Shipping

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 4
G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 5

Certification

G350 Z180 Gi Steel Galvanized Steel Coil Full Hard 0.5mm For Roofing 6

FAQ


Q: Can we visit your factory ?
A:Warmly welcome once we have your schedule we will pick you up .


Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.


Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
