ASTM A333 Seamless Carbon Steel Tube Pipe 16MnDG For Low Temperature

  • ASTM A333 Seamless Carbon Steel Tube Pipe 16MnDG For Low Temperature
  • ASTM A333 Seamless Carbon Steel Tube Pipe 16MnDG For Low Temperature
  • ASTM A333 Seamless Carbon Steel Tube Pipe 16MnDG For Low Temperature
Place of Origin China
Brand Name ANSTEEL
Certification ISO 9001
Model Number ASTM A333
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details Seaworthy Packing For Exporting
Delivery Time 7-10 days
Payment Terms L/C, T/T, Western Union
Supply Ability 50000 Tons/Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Thickness As Required Length 3m, 6m Or As Required
Shape Round Delivery Time 8-14 Days
Processing Service Bending, Welding, Cutting, Punching Application -45℃ ~ -195℃ Cryogenic Pressure Vessel Pipes And Cryogenic Heat Exchanger Pipes
Highlight

Seamless Carbon Steel Tube Pipe

,

ASTM A333 Carbon Steel Tube

,

16MnDG Carbon Steel Tube
Leave a Message
Product Description

ASTM A333 16MnDG Seamless Carbon Steel Tube Pipe for Low Temperature



Product Description

ASTM A333 is the standard specification for seamless and welded steel pipe for application in low temperature services and other applications with the required notch toughness.



All the seamless and welded steel pipe, except ASTM A333 Grade 8 and Grade 11, shall be treated to control the microstructure in one option as follows,

1. Normalized in a uniform temperature not less than 815℃ [1500℉], and cool in air or in the cooling chamber of an atmosphere controlled furnace, or after this heat treatment then heating to a suitable temperature to do the termpering.

2. Besides above heat treatment option, and with manufacturers will, reheat material to a suitable tempering temperature.

3. In case the seamless steel pipe in the ASTM A333, reheat and control hot working and the temperature of the hot finishing operation to a finishing temperature range from 845 to 945℃ [1550 to 1750℉], and cool in air or in a controlled atmosphere furance from an initial temperature more than 845℃ [1550℉]. For the ASTM A333 seamless steel pipe in Grade 1, Grade 6, and Grade 10 could be heat treated from a uniform temperature more than 815℃ [1500℉], then quenching in liquid and reaheat to a suitable tempering temperature, this type of heat treatment could replace the above plan also provided the ASTM A333 4.3.1. For the ASTM A333/ A333M Grade 8 and Grade 11, heating treatment shall be complied the standard specification.

For the ASTM A333 Grade 1, Grade 6 and Grade 10 steel pipe, and it is not allowed to add the chemical element not specified in the specification, but it is allowed to add the element for the deoxidation of steel.



Chemical composition

Standard
Grade
C
 Si Mn P S Cr Ni Cu Mo V Al
GB/T18984
-2003
16MnDG
0.12-0.20
0.20-0.55
1.20-1.60
≤0.025
≤0.025
--
--
--
--
--
--
10MnDG
≤0.13
0.17-0.37
≤1.35
≤0.025
≤0.025
--
--
--
--
≤0.07
--

09DG
≤0.12
0.17-0.37
≤0.95
≤0.025
≤0.025
--
--
--
--
≤0.07
--

09Mn2VDG
≤0.12
0.17-0.37
≤1.85
≤0.025
≤0.025
--
--
--
--
≤0.12
--

06Ni3MoDG
≤0.08
0.17-0.37
≤0.85
≤0.025
≤0.025
--
2.5-3.7
--
0.15-0.30
≤0.05
--

ASTM A333
Grade1
≤0.30
--
0.40-1.06
≤0.025
≤0.025
--
--
--
--
--
--
Grade3
≤0.19
0.18-0.37
0.31-0.64
≤0.025
≤0.025
--
3.18-3.82
--
--
--
--

Grade4
≤0.12
0.18-0.37
0.50-1.05
≤0.025
≤0.025
0.44-1.01
0.47-0.98
0.40-0.75
--
--
0.04-0.30

Grade6
≤0.30
≥0.10
0.29-1.06
≤0.025
≤0.025
--
--
--
--
--
--

Grade7
≤0.19
0.13-0.32
≤0.90
≤0.025
≤0.025
--
2.03-2.57
--
--
--
--

Grade8
≤0.13
0.13-0.32
≤0.90
≤0.025
≤0.025
--
8.40-9.60
--
--
--
--

Grade9
≤0.20
--
0.40-1.06
≤0.025
≤0.025
--
1.60-2.24
0.75-1.25
--
--
--

Grade10
≤0.20
0.10-0.35
1.15-1.50
≤0.030
≤0.015
≤0.15
≤0.25
≤0.015
≤0.50
≤0.12
≤0.06

Grade11
≤0.10
≤0.035
≤0.60
≤0.025
≤0.025
≤0.50
35.0-37.0
--
≤0.50
--
--
